Digital low-voltage switchgear

Mdmax digital low-voltage switchgear technical parameters
name	unit	data
Rated working voltage	V	400/690 AC, 3P, 750 DC
Rated insulation voltage	V	690/1000 AC, 3P, 1500 DC
Rated pulse withstand voltage-Uimp	kV	6,8,12
Overvoltage level	kV	II/III/IV
pollution level	Hz	60
Rated current of main busbar le	A	6300
Rated peak withstand current lpk of main busbar	kA	220
Rated short-time withstand current of main busbar lcw	kA	100
Rated current of distribution busbar le	A	3200 (fixed split type) 2500 (drawer style)
Rated peak withstand current lpk of distribution busbar	kA	220
Rated short-time withstand current of distribution busbar lcw	kA	85
